Mobil Power AD 5000 digital

ultra high-capacity 12 volt battery unit for mobile, extreme applications and heavy vegetative growth

Digital Display Readout and LED Lights for Fence and Battery Voltage

recommended solar module: 375559 (55 W), connection directly to the 12-Volt battery - ideal with ground anchor kit 442382

Ref. no.	PU	Pallet
372591	1	33 PAL

with 12 Volt full discharge protection
The shock strength can be steplessly adjusted with the manual controller (1 - 20)
Can be operated via a 230-V power pack (371012 - not included)
integrated solar charge controller
digital display to indicate the fence voltage, battery voltage and power level
robust, impact-resistant, UV-resistant and weather-resistant housing thanks to the use of high-quality plastics
large battery container for the 12-Volt battery
microprocessor controlled
very bright, clearly visible LED light
corresponds to applicable EU safety standards

Model	Ref. no.	Stored Energy	max. discharge energy	min. discharge energy	max. voltage	Voltage in Open Circuit	Voltage at 500 Ohms	theoretical fence length as per VDE	max. fence length without vegetation	max. fence length with medium vegetation	max. fence length with high vegetation	Approx. Number of Electrifiable Nets	Qty 1 m earth posts	Power Consumption
AD 5000 digital	372591	7.4 J	4.6 J	1 J	11000 V	10000 V	6500 V	115 km	38 km	14 km	5.5 km	18	5	100 mA - 460 mA
