Mobil Power A 1200

Universal, very effective 12 volt battery unit for mobile use
two separate LEDs for fence voltage and battery control
manual turn switch (1 – 10) adjusts output energy steplessly – this makes power input adjustable to adapt more efficiently to fencing conditions
Can be operated via a 230-V power pack (371012 - not included)

recommended solar module: item no. 375156 (15 watts)

Items

Ref. no.	PU		Pallet
372121	1	1	33 PAL	33 PAL

Accessories

Ref. no.	Description	Width	Depth	Height	PU
375156	Solar Panel without charge controller	37.5 cm	2 cm	37 cm	1

low energy consumption thanks to energy-saving mode
with visual fence voltage control
with On/Off switch, high/low
weather-resistant and sturdy housing
Can be operated via a 230-V power pack (371012 - not included)
with 12 Volt full discharge protection

Model	Ref. no.	Stored Energy		max. discharge energy		min. discharge energy		max. voltage		Voltage in Open Circuit		Voltage at 500 Ohms		theoretical fence length as per VDE		max. fence length without vegetation		max. fence length with medium vegetation		max. fence length with high vegetation		Approx. Number of Electrifiable Nets		Qty 1 m earth posts		Power Consumption
A 1200	372121	2.1 J	2.1 J	1.4 J	1.4 J	0.48 J	0.48 J	10700 V	10700 V	9000 V	9000 V	4400 V	4400 V	40 km	40 km	10 km	10 km	5 km	5 km	1.5 km	1.5 km	5	5	2	2	15 mA - 150 mA	15 mA - 150 mA
