Duo Power X 1000

12 V / 230 V DUO unit with effective output power
for short fences without vegetation

5-year warranty

Function control LED and visual battery warning indicator

recommended solar module: item number 375151 (15 Watt), connection directly to the 12-Volt battery, mounting e.g. on a metal box

Items

Ref. no.	PU		Pallet
372871	1	1	88 PAL	88 PAL

Accessories

Ref. no.	Description	Width	Depth	Height	PU
375151	Solar Panel incl. charge controller	37.5 cm	2 cm	37 cm	1

optimised power consumption thanks to energy-saving mode
deep discharge protection with 12 V operation
microprocessor controlled
plug connector with screw fuse
robust, impact-resistant, UV-resistant and weather-resistant housing thanks to the use of high-quality plastics
integrated hanging device for wall mounting
very bright, clearly visible LED light
corresponds to applicable EU safety standards
(suitable for metal box 44656 and 44650)

Model	Ref. no.	Stored Energy		max. discharge energy		max. voltage		Voltage in Open Circuit		Voltage at 500 Ohms		theoretical fence length as per VDE		max. fence length without vegetation		max. fence length with medium vegetation		max. fence length with high vegetation		Approx. Number of Electrifiable Nets		Qty 1 m earth posts		Power Consumption
X 1000	372871	1.6 J	1.6 J	1 J	1 J	10500 V	10500 V	9000 V	9000 V	4400 V	4400 V	35 km	35 km	10 km	10 km	1.5 km	1.5 km	0.8 km	0.8 km	4	4	1	1	115 mA	115 mA

1 x fence unit
1 x 230 volt power pack (371023)
1 x 12-Volt connection cable (E268739)
1 x ground connector cable
1 x fence connector cable

Preview image	Item. No.	Description	372871
	AKO268861	Knurled nut M8 BIG black	x
	AKO268862	Knurled nut M8 BIG red	x
