Sun Power S 1000

  • powerful solar device for normal fence systems with little vegetation
  • ideal for horse and cattle paddocks as well as poultry nets

function indicator LED (green) plus solar operation LED (blue) plus battery warning LED (red)

Important: If ground is dry, several additional ground rods must be used.
Items
Ref. no.PUPallet
3729501150 PAL50 PAL


  • optimised for permanent, maintenance-free operation right through the main pasture season
  • with High/Low/Off switch
  • power saving switch for when battery voltage fails
  • integrated lightning protection
  • intelligent, modern battery management with deep discharge protection – device functions even during extended periods of bad weather
  • excellent level of efficiency – therefore a longer battery life
  • very robust, weather-resistant, water-tight casing with carrying handle
  • fast and easy to install
  • channel integrated into the housing for post mounting
  • microprocessor controlled
  • very bright, clearly visible LED light
  • corresponds to applicable EU safety standards

Model
S 1000
Ref. no.372950
Stored Energy1.4 J
1.4 J
max. discharge energy1 J
1 J
max. voltage11000 V
11000 V
Voltage in Open Circuit10000 V
10000 V
Voltage at 500 Ohms5000 V
5000 V
theoretical fence length as per VDE35 km
35 km
max. fence length without vegetation10 km
10 km
max. fence length with medium vegetation2.5 km
2.5 km
max. fence length with high vegetation1 km
1 km
Approx. Number of Electrifiable Nets4
4
Qty 1 m earth posts1
1
Power Consumption59 mA - 81 mA
59 mA - 81 mA
ModelS 1000
Ref. no.372950
Stored Energy1.4 J
1.4 J
max. discharge energy1 J
1 J
max. voltage11000 V
11000 V
Voltage in Open Circuit10000 V
10000 V
Voltage at 500 Ohms5000 V
5000 V
theoretical fence length as per VDE35 km
35 km
max. fence length without vegetation10 km
10 km
max. fence length with medium vegetation2.5 km
2.5 km
max. fence length with high vegetation1 km
1 km
Approx. Number of Electrifiable Nets4
4
Qty 1 m earth posts1
1
Power Consumption59 mA - 81 mA
59 mA - 81 mA

  • 1 x High-Power Compact Solar Device Sun Power S 1000 (fully assembled) *
  • 1 x AGM battery, 12 Volt, 12 Ah (441124)*
  • 1 x permanently mounted, crystalline solar module, 12 Volt, 8 Watt *
  • 1 x 230 volt battery mains charger (371032)
  • 1 x fence connector cable
  • 1 x ground connector cable
  • 1 x two-part ground/installation spear (442385)
  • 1 x warning sign
  • * Warranty: solar fence device (4 year warranty), solar module (5 year performance warranty), 12 volt battery (6 month warranty)

Preview imageItem. No.Description372950
 441124Spare Battery 12 V, 12 Ahx
