AKO Smart Satellite

The Smart Satellite for connection to the Kerbl Welt app allows you to check the fence voltage at any time in real time and from any location.

  • for mobile monitoring of the set minimum guard voltage on the fence
  • real-time alarm message in the app if the voltage falls below the minimum guard voltage preset directly on the satellite (selectable between 3 kV, 5 kV, 7 kV)
  • thanks to the satellite's direct connection to the cloud, no WLAN is required, making it easy to monitor fence systems from any location

Utility model application registered!

Items
Ref. no.PUPallet
4411441/34612 PAL

Flexible in use: the AKO Smart Satellite can be integrated into any fence system and used for all types of fence device. It accurately measures the fence voltage at that point and reports the values regularly to the app

Power supply and cloud: the Smart Satellite is operated with 2 x AA batteries which are included in the scope of delivery and last around one pasture season. Thanks to the direct connection to the cloud, no WLAN is required

Functions: the Smart Satellite measures the fence voltage at the installed point in the fence system. If the selected minimum protective voltage is not reached, it offers a real-time alarm message in the app

Display: the device is equipped with a total of 4 LEDs. The top LED flashes green if the fence voltage is OK and flashes red if the minimum protective voltage is not reached. 3 further LEDs are used to define the fence alarm threshold

Housing and assembly: the Satellite's robust housing is made from impact-resistant, UV-resistant plastic, making it weather-proof and long-lasting. The device is mounted directly on the post and connected to the conductor material and the earth

Advantages of the Kerbl Welt app:

  • free download
  • use of all functions without follow-up costs and permanently free mobile data transfer from the Smart Satellite to the app
  • unlimited number of smart devices and users can be linked
  • checking the current fence and supply voltage as well as an overview of the historical trends
  • Smart Satellite operates entirely independently of the fence device used in the fence system
  • multiple smart satellites can be used in a single fence system in order to improve the protective safety and any number of satellites can be monitored with one user account

  • 1 x AKO Smart Satellite
  • 2 x AA batteries
  • 1 x earth cable with ground rod
  • 1 x fence connector cable
  • 1 x stainless steel clamp for connection directly to the conductor material
